DGT Solutions robotic palletizing machines handle and stack cases, bags, drums, pails and other packaged products according to programmed pallet patterns. Vacuum, mechanical, fork or custom tooling provides the gripping method required for each application.
Single and dual-robot configurations can incorporate pallet magazines, automatic dispensing and suitable tooling for empty-pallet or slip-sheet handling. HMI controls support product selection and changeover, while integrated conveyors and stretch-wrapping equipment can extend the process through to wrapped pallet discharge.
Robotic handling, pallet supply and programmed stacking form the palletizing operation. Additional handling and wrapping equipment can extend the system.
The robot picks and transfers products using tooling matched to their geometry and handling requirements. Vacuum, mechanical, fork and custom gripping arrangements serve different products.
Picture note: A robot gripping the same product type shown elsewhere on the page, with the end-of-arm tool visible.
Empty pallets are held in a magazine for dispensing and robotic handling. The magazine is replenished manually or with a forklift, with the dispensing arrangement selected around the cell layout.
Picture note: A pallet magazine or dispenser transferring an empty pallet into the cell.
A suitably configured robot tool can place separator sheets between product layers. This adds sheet handling to the palletizing operation where the load requires it.
Picture note: The gripper lifting or placing a separator sheet between layers
A suitably configured robot tool can place separator sheets between product layers. This adds sheet handling to the palletizing operation where the load requires it.
Picture note: The bottom-sealing station or a formed box leaving the former. Show the actual sealing method used.
An integrated rotary conveyor presents the completed load to the stretch-wrapping system. Film is applied around the pallet, then pinched and cut before discharge.
Picture note: A loaded pallet at the wrapping station with the film carriage visible.
| Configuration Type | Available Choices |
|---|---|
| Robotic arrangement | |
| Gripping system | |
| Pallet dispensing layout | |
| Optional robot handling | |
| Optional line integration | |
AVAILABLE CONFIGURATIONSThe ACPM can be configured to match different production layouts, packaging formats, and throughput requirements. |
|---|
Product Flow Layout Choices |
Container Type Choices |
Pick & Place System Choices |
Sealing Method Choices |
| Configuration type | Available choices |
|---|---|
| Robotic arrangement |
Single robot
Dual robot
|
| Gripping system |
Vacuum
Mechanical
Fork
Custom
|
| Pallet dispensing layout |
Floor-mounted
Conveyor-mounted
Mezzanine-mounted
|
| Optional robot handling |
Slip-sheet placement
|
| Optional line integration |
Pallet conveying
Stretch wrapping
|
Contact DGT Solutions to discuss the right configuration for your production requirements.
